5D-Link DIR-825+ User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 Power The Power LED indicates that the device is powered on with a proper connection to the power supply.
2 Internet The Internet LED indicates that an Internet link is established. It blinks during data transmission.
3 WPS The WPS LED blinks during the WPS pairing process.
4 2.4 GHz Wireless The Wireless LED indicates that this wireless band is working. It blinks during wireless data transmission.
5 5 GHz Wireless The Wireless LED indicates that this wireless band is working. It blinks during wireless data transmission.
6 LAN Port (1-4) The LAN Port LEDs indicate an Ethernet device is connected. They blink during data transmission.
7 USB The USB LED indicates that a USB device is connected to the USB 2.0 port.
1 2 3 4 5 76
