DIS-200G Series Layer 2 Gigabit Industrial Smart Managed Switch Hardware Installation Guide
10
LED Description
1 Power Input
This is used to connect an external power adapter to the switch.
Top Panel Components
Figure 1-3 Top panel view of the DIS-200G Series switches
Ports that can be found on the top panel of this switch are listed in the table below.
LED Description
1 Switch Ground
This is used to connect the switch to ground.
2 Terminal Block
This is used to connect the switch to external power sources and an alarm relay.
