D-Link DPH-400G - Page 41

QoS &VLAN
LLDP Settings
Enable LLDP
Enable LLDP by selecting it.
Enable Learning
Function
After enabling LLDP Learn, telephone can
automatically learn the data of DSCP, 802.1p, VLAN
ID from the switch. If the data is different from the
data of the LLDP server, telephone will change its
own value as the value of the switch (Synchronous
with VLAN in switch).
Package Interval
The time interval of sending LLDP Packet.
QoS Setting
Enable DSCP
Enable Dscp by selecting it.
SIP DSCP
Specify the value of the SIP Dscp.
Audio RTP DSCP
Specify the value of the Audio RTP Dscp.
WAN Port VLAN
Setting
Enable WAN Port
VLAN
Enable WAN Port VLAN by selecting it.
WAN Port VLAN
ID
Specify the value of the WAN Port VLAN ID, the
range of the value is 0-4095.
