DSL-2520U ADSL2/2+ Router with USB and Ethernet Ports
User Manual
Configuring via Web-based Interface
If needed, change the connection settings available in the Miscellaneous section.
Figure 31. Configuring Dynamic IP WAN connection.
Parameter Description
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Click the Next button to continue.
If needed, change the connection settings available in the VLAN section.
Figure 32. Configuring Dynamic IP WAN connection.
Page 35 of 83
