DSL-2520U ADSL2/2+ Router with USB and Ethernet Ports
User Manual
Configuring via Web-based Interface
Parameter Description
General settings
Connection Type
A type of network protocol to be used by the connection. Available
values:
• PPPoA
• PPPoE
• Static IP
• Dynamic IP
• IPoA
• Bridge.
Port
A physical interface to which the new connection will be assigned.
Leave the DSL(new) value to create a new interface at the physical
layer.
Name
A name for connection for easier identification.
Enable
Select the checkbox to enable the connection.
Direction
The direction of this connection.
ATM
VPI
Virtual Path Identifier. The valid range is from 0 to 250.
VCI
Virtual Circuit Identifier. The valid range is from 32 to 65535.
Encapsulation Mode Select LLC or VC from the drop-down list.
QoS A class of traffic for this connection.
UBR
(Unspecified Bit Rate): The UBR service is used for applications
that allow various delays and losses of packets. It is appropriate to
use the UBR service for text/data/image transfer applications, as
well as messaging, distribution, retrieval, and remote terminal
applications.
UBR With PCR
(Unspecified Bit Rate with Peak Cell Rate): The UBR service is
used for applications that allow various delays and losses of
packets. The Peak Cell Rate is a determining factor in how often
cells are sent in an effort to minimize lag or jitter caused by traffic
inconsistencies. When you select this value from the drop-down list,
