DSL-2520U ADSL2/2+ Router with USB and Ethernet Ports
User Manual
Configuring via Web-based Interface
Figure 61. The page for adding a rule for IP filtering.
You can specify the following parameters:
Parameter Description
IP filter rule editing
Name
A name for the rule for easier identification.
Protocol
A protocol for network packet transmission. Select a value from the
drop-down list. To apply the rule to all protocols from the list, select
the <All> value (when this value is selected, the Ports section is not
displayed).
Action
Select an action for the rule.
ACCEPT: Allows packet transmission in accordance with the
criteria specified by the rule.
DROP: Denies packet transmission in accordance with the criteria
specified by the rule.
IP Addresses
IP address range
Select the checkbox if you want to specify a range of IP addresses as
the source or destination IP address.
Page 66 of 83
