D-Link DSL-2520U User Manual

DSL-2520U ADSL2/2+ Router with USB and Ethernet Ports
User Manual
Configuring via Web-based Interface
Control Description
Server
The IP or URL address of the host from the local or global network,
to which the system log will be sent.
Port
A port of the host specified in the Server field. By default, the
value 514 is specified.
After specifying the needed parameters, click the Change button.
To disable logging of the system events, deselect the Logging checkbox and click the Change
button.
On the Log tab, the events specified in the Logging level list are displayed.
Figure 76. The System / System log page. The Log tab.
To view the latest system events, click the Refresh button.
To save the system log to your PC, click the Export button and follow the dialog box appeared.
Page 80 of 83

D-Link DSL-2520U Specifications

Data Transfer Rates

ADSL full rate downstream	up to 8 Mbps
ADSL full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL2 full rate downstream	up to 24 Mbps

Interfaces

ADSL interface connector	RJ-11
LAN interface	RJ-45 port for 10/100BASE-T Ethernet
USB interface	USB port Type B connector, USB 1.1 Specification
