D-Link DSL-2740B User Manual

93
Log Level
All events above or equal to the selected level will be logged.
Display Level
All logged events above or equal to the selected level will be displayed.
Mode
Display mode of system log.
• Local: Display on local host only
• Remote: Send log file to remote syslog server only
• Both: Display on local host and send to syslog server concurrently
Server IP Address
IP address of the remote syslog server
Server UDP Port
UDP port number of the remote syslog server

D-Link DSL-2740B Specifications

ADSL Standards

downstream data rate	up to 8 Mbps
upstream data rate	up to 1 Mbps
G.lite downstream data rate	up to 1.5 Mbps
G.lite upstream data rate	up to 512 Kbps
G.dmt.bis downstream data rate	up to 12 Mbps
G.dmt.bis upstream data rate	up to 12 Mbps

ADSL2 Standards

full rate downstream data rate	up to 24 Mbps
full rate upstream data rate	up to 1 Mbps

Wireless LAN

wireless speed	up to 300 Mbps
frequency range	2.4 GHz to 2.484 GHz
antennas	2 non-detachable dipole
