DSL-G2452GR AC1200 MU-MIMO Wireless Dual Band
VDSL2 Router with ADSL2+/3G/LTE/Gigabit Ethernet WAN
Support, 2 FXS Ports and USB Port
User Manual
Configuring via Web-based Interface
You can specify the following parameters:
Parameter Description
Tunnel settings
Enable
Move the switch to the right to enable the GRE tunnel.
Move the switch to the left to disable the GRE tunnel.
Name
A name of the tunnel for easier identification. You can specify any
name.
IP address
The IP address of the GRE tunnel interface.
Mask
The mask of the subnet.
Interface
From the drop-down list, select a WAN connection through which
the tunnel will pass. Select the Default gateway value to use the
default WAN connection.
Remote IP
Enter the public IP address of the remote subnet VPN gateway.
MTU
The maximum size of units transmitted from the remote host to the
router.
Allow traffic GRE →
LAN
Move the switch to the right to allow GRE tunnel users access
devices in the remote local subnet.
Static route settings
Remote LAN IP address
The IP address of the remote local subnet.
Remote LAN mask
The mask of the remote local subnet.
Remote GRE interface
IP address
The IP address of the GRE tunnel interface in the remote subnet.
After configuring all needed settings, click the APPLY button.
To edit the parameters of an existing tunnel, in the Tunnels section, select the relevant tunnel in the
table. On the opened page, change the needed parameters and click the APPLY button.
To remove an existing tunnel, select the checkbox located to the left of the relevant line in the table
and click the DELETE button ( ).
Page 164 of 358
