DSL-G2452GR AC1200 MU-MIMO Wireless Dual Band
VDSL2 Router with ADSL2+/3G/LTE/Gigabit Ethernet WAN
Support, 2 FXS Ports and USB Port
User Manual
Configuring via Web-based Interface
EoGRE
On the VPN / EoGRE page, you can configure VPN tunnels based on EoGRE technology.
EoGRE (Ethernet over GRE) technology allows transferring traffic through VPN tunnels in
heterogeneous networks, encapsulating Ethernet frames with the help of GRE protocol and
transferring them over a network which uses a network protocol of another level.
Figure 136. The VPN / EoGRE page.
To create a new tunnel, click the ADD button ( ).
Figure 137. The page for adding an EoGRE tunnel.
You can specify the following parameters:
Parameter Description
Enable
Move the switch to the right to enable the EoGRE tunnel.
Move the switch to the left to disable the EoGRE tunnel.
Name
A name of the tunnel for easier identification. You can specify any
name.
Page 171 of 358
