DSL-G2452GR AC1200 MU-MIMO Wireless Dual Band
VDSL2 Router with ADSL2+/3G/LTE/Gigabit Ethernet WAN
Support, 2 FXS Ports and USB Port
User Manual
Installation and Connection
Connecting to PC
PC with Ethernet Adapter
1. Connect an Ethernet cable between any of LAN ports located on the back panel of the router
and the Ethernet port of your PC.
2. To connect via USB modem: connect your USB modem to the USB port
7
located on the
right side panel of the router.
!
In some cases you will need to reboot the router after connection of the USB modem.
3. To connect the device to a DSL line: connect a phone cable between the DSL port of the
router and the MODEM port of the splitter. Connect your phone to the PHONE port of the
splitter. Then connect another phone cable between a phone jack and the LINE port of the
splitter.
4. To connect the device to an Ethernet line: connect an Ethernet cable between the WAN port
of the router and the Ethernet line.
5. Connect another phone cable between an FXS port of the router and the phone.
6. Connect the power cord to the power connector port on the back panel of the router, then
plug the power adapter into an electrical outlet or power strip.
7. Turn on the router by pressing the power button on its right side panel.
Then make sure that your PC is configured to obtain an IP address automatically (as DHCP client).
7 It is recommended to use a USB extension cable to connect a USB modem to the router.
