DSL-G2452GR AC1200 MU-MIMO Wireless Dual Band
VDSL2 Router with ADSL2+/3G/LTE/Gigabit Ethernet WAN
Support, 2 FXS Ports and USB Port
User Manual
Configuring via Web-based Interface
Figure 204. The window for specifying signal parameters.
In the opened window, fill in the Signal length and Pause length fields. For each ring, you can
specify several variants of signal and pause length in milliseconds which will be used cyclically in
the order of their appearance on the page.
Click the SAVE button.
To edit the parameters of a signal, in the Signal List section, select the corresponding line in the
table. In the opened window, change the needed parameters and click the SAVE button.
When all needed settings are configured, click the APPLY button.
To edit the parameters of a ring, in the Rings List section, select the corresponding line in the
table. On the displayed page, change the needed parameters and click the APPLY button.
To remove an existing ring, select the checkbox located to the left of the relevant line in the table
and click the DELETE button ( ).
Page 268 of 358
