DSL-G2452GR AC1200 MU-MIMO Wireless Dual Band
VDSL2 Router with ADSL2+/3G/LTE/Gigabit Ethernet WAN
Support, 2 FXS Ports and USB Port
User Manual
Configuring via Web-based Interface
The ATM section is displayed for ADSL WAN connections.
Figure 73. The page for creating a new Static IPv4 connection. The ATM section.
Parameter Description
ATM
VPI
Virtual Path Identifier. The valid range is from 0 to 255.
VCI
Virtual Circuit Identifier. The valid range is from 32 to 65535.
Encapsulation
Select LLC or VCMUX from the drop-down list.
QoS class
A class of traffic for this connection.
• UBR (Unspecified Bit Rate): The UBR service is used for
applications that allow various delays and losses of packets.
It is appropriate to use the UBR service for text/data/image
transfer applications, as well as messaging, distribution,
retrieval, and remote terminal applications.
• UBR with PCR (Unspecified Bit Rate with Peak Cell
Rate): The UBR service is used for applications that allow
various delays and losses of packets. The Peak Cell Rate is a
determining factor in how often cells are sent in an effort to
minimize lag or jitter caused by traffic inconsistencies.
When you select this value from the drop-down list, the
Peak cell rate field is displayed. Specify a required value
(in cells per second).
