D-Link DWA-110 Manual

2
Using the Configuration Utility with Macintosh OS
(continued)
This window will ap-
pear displaying the
Network Name,
BSSID; Link State;
Network Type ;
Channel and
Signal Strengh.
SSID;BSSID;Signal ;
Channel;
Authentication;
Encryption
Advanced：Wireless Mode;11 B/G Protection ; TX Rate
Info: Configuration Utility Version; MAC Address; Driver Version;
EEPROM Version
following:
Current Wireless
Network settings:
Available Wireless
Networks including:
Start Scan:
Click Start Scan to
rescan for an avail-
able wireless net-
work at your current
location.
Connect: Highlight a network profile and click Connect to connect
to that net-work profile.
Wireless Adaptor Settings:
Click Open Profile Drawer to manage your network profiles.

D-Link DWA-110 Specifications

General

Wi-Fi	Yes
Modulation	DBPSK
Wi-Fi band	Single-band (2.4 GHz)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2-PSK
Maximum data transfer rate	54 Mbit/s
Connectivity technology	Wireless
Output voltage	5 V
RX power consumption	280 mA
Dimensions (WxDxH)	87 x 28 x 12 mm
Compliance industry standards	IEEE 802.11g/b
Compatible operating systems	Windows 98SE, ME, XP SP2, 2000 SP4, Vista
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Certification	FCC Class B, CE, C-Tick, IC, Wi-Fi, WPS
