D-Link DWL-6610AP User Manual

Configuring MLD Snooping
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 231
D-Link UWS User Manual
Multicast Router Status
Use the MLD Snooping Multicast Router Status page to view multicast router functionality on selected ports.
To access this page, click Monitoring > MLD Snooping > Multicast Router Status in the navigation tree.
Figure 136: MLD Snooping Multicast Router Status
• Click Refresh to re-display the page with the latest information from the router.
Table 120: MLD Snooping Multicast Router Status Fields
Field Description
Slot/Port Select the slot and port number with the information to view.
Multicast Router Indicates whether the specified interface is configured to perform multicast
routing.

D-Link DWL-6610AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Certification	CE EN 301 893 V1.7.1 (2012-06) (DFS/TPC) EN 300 328 V1.8.1 (2012-06) FCC IC cUL LVD UL2043 C-Tick BSMI NCC
Housing material	Plastic
Antenna gain level (max)	6.5 dBi
Security algorithms	AES, HTTPS, SSH, TKIP, WPA, WPA2
Output current	2 A
Output voltage	12 V
Power consumption (max)	16.6 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	1
Package depth	235 mm
Package width	243 mm
Package height	90 mm
Package weight	1065 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1235 mm
Pallet height (sea)	2060 mm
Pallet gross weight (air)	200628 g
Pallet gross weight (sea)	332474 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	252 pc(s)
Shipping (inner) case width	343 mm
Shipping (inner) case height	275 mm
Shipping (inner) case length	565 mm
Shipping (inner) case weight	7297 g
Shipping (inner) case net weight	6390 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	42 pc(s)
Quantity per shipping (inner) case	6 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	158.8 mm
Height	69.4 mm
Weight	500 g
