D-Link DWL-6610AP User Manual

Configuring Dynamic ARP Inspection
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 278
D-Link UWS User Manual
DAI ARP ACL Rule Configuration
Use the DAI ARP ACL Rule Configuration page to add or remove DAI ARP ACL Rules.
To display the DAI ARP ACL Rule Configuration page, click LAN > L2 Features>Dynamic ARP Inspection > DAI
ARP ACL Rule Configuration in the navigation tree.
Figure 175: Dynamic ARP Inspection ARP ACL Rule Configuration
• Click Add to add a new ARP ACL rule.
• Click Submit to delete the entries selected in the Remove column.
• Click Refresh to refresh the page with the most current data from the switch.
Table 158: Dynamic ARP Inspection ARP ACL Rule Configuration
Field Description
ARP ACL Name Select the ARP ACL for which information is to be displayed or configured.
Sender IP Address To create a new rule for the selected ARP ACL, enter in this field the Sender IP Address
match value for the ARP ACL.
Sender MAC
Address
To create a new rule for the selected ARP ACL, enter in this field the Sender MAC Address
match value for the ARP ACL.
Remove Use the Remove column to select the particular ARP ACL Rules you want to delete.

D-Link DWL-6610AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Certification	CE EN 301 893 V1.7.1 (2012-06) (DFS/TPC) EN 300 328 V1.8.1 (2012-06) FCC IC cUL LVD UL2043 C-Tick BSMI NCC
Housing material	Plastic
Antenna gain level (max)	6.5 dBi
Security algorithms	AES, HTTPS, SSH, TKIP, WPA, WPA2
Output current	2 A
Output voltage	12 V
Power consumption (max)	16.6 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	1
Package depth	235 mm
Package width	243 mm
Package height	90 mm
Package weight	1065 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1235 mm
Pallet height (sea)	2060 mm
Pallet gross weight (air)	200628 g
Pallet gross weight (sea)	332474 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	252 pc(s)
Shipping (inner) case width	343 mm
Shipping (inner) case height	275 mm
Shipping (inner) case length	565 mm
Shipping (inner) case weight	7297 g
Shipping (inner) case net weight	6390 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	42 pc(s)
Quantity per shipping (inner) case	6 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	158.8 mm
Height	69.4 mm
Weight	500 g
