D-Link DWL-6610AP User Manual

System Description
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 63
D-Link UWS User Manual
System Description
After a successful login, the System Description page displays. Use this page to configure and view general
device information.
To display the System Description page, click LAN > Administration > System Description in the navigation
tree.
Figure 7: System Description
Table 3: System Description Fields
Field Description
System Description The product name of this switch.
System Name Enter the name you want to use to identify this switch. You may use up to 31 alpha-
numeric characters. The factory default is blank.
System Location Enter the location of this switch. You may use up to 31 alpha-numeric characters. The
factory default is blank.
System Contact Enter the contact person for this switch. You may use up to 31 alpha-numeric
characters. The factory default is blank.
IP Address The IP Address assigned to the network interface. To change the IP address, see
“Serial Port” on page 73.
System Object ID The base object ID for the switch's enterprise MIB.
System Time (yyyy-
mm-dd h:m:s)
Enter the current date and time that the switch will follow using the on-board real-
time clock.
System Up Time Displays the number of days, hours, and minutes since the last system restart.
Current SNTP
Synchronized Time
Displays currently synchronized SNTP time in UTC. If no SNTP server has been
configured and the time is not synchronized, this field displays “Not Synchronized.”
To specify an SNTP server, see “Configuring SNTP Settings” on page 97.

D-Link DWL-6610AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Certification	CE EN 301 893 V1.7.1 (2012-06) (DFS/TPC) EN 300 328 V1.8.1 (2012-06) FCC IC cUL LVD UL2043 C-Tick BSMI NCC
Housing material	Plastic
Antenna gain level (max)	6.5 dBi
Security algorithms	AES, HTTPS, SSH, TKIP, WPA, WPA2
Output current	2 A
Output voltage	12 V
Power consumption (max)	16.6 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	1
Package depth	235 mm
Package width	243 mm
Package height	90 mm
Package weight	1065 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1235 mm
Pallet height (sea)	2060 mm
Pallet gross weight (air)	200628 g
Pallet gross weight (sea)	332474 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	252 pc(s)
Shipping (inner) case width	343 mm
Shipping (inner) case height	275 mm
Shipping (inner) case length	565 mm
Shipping (inner) case weight	7297 g
Shipping (inner) case net weight	6390 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	42 pc(s)
Quantity per shipping (inner) case	6 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	158.8 mm
Height	69.4 mm
Weight	500 g
