D-Link DWL-6610AP User Manual

Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 639
D-Link UWS User Manual
Switch Provisioning
Use the Switch Certificate Request page to request a X.509 certificate from the cluster controller. The X.509
mutual certificate exchange is the only mechanism for peer switches to authenticate with each other because
switches do not support pass-phrase authentication.
The X.509 certificate is automatically generated by the switch, so it does not communicate with any trusted
certificate authority, and there are no certificate maintenance fees.
Figure 399: Switch Certificate Request
The following table shows the fields available on the Switch Certificate Request page.
Command Buttons
The page includes the following buttons:
• Start—Initiates the X.509 certificate request.
• Refresh—Updates the page with the latest information.
Table 366: Switch Certificate Request
Field Description
Switch IP Address Enter the IP address of the wireless switch from which this switch
requests an X.509 certificate.
Switch Certificate Request Status Shows the status of the request, which is one of the following:
• Not Started—Certificate exchange has not started.
• Invalid IP address—IP address specified in the Switch IP Address
field is not valid.
• In Progress—Certificate request is in progress.
• Success—Certificate has been obtained and added to the
certificate file.
• Timed Out—Certificate request timed out without getting a
certificate.

D-Link DWL-6610AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Certification	CE EN 301 893 V1.7.1 (2012-06) (DFS/TPC) EN 300 328 V1.8.1 (2012-06) FCC IC cUL LVD UL2043 C-Tick BSMI NCC
Housing material	Plastic
Antenna gain level (max)	6.5 dBi
Security algorithms	AES, HTTPS, SSH, TKIP, WPA, WPA2
Output current	2 A
Output voltage	12 V
Power consumption (max)	16.6 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	1
Package depth	235 mm
Package width	243 mm
Package height	90 mm
Package weight	1065 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1235 mm
Pallet height (sea)	2060 mm
Pallet gross weight (air)	200628 g
Pallet gross weight (sea)	332474 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	252 pc(s)
Shipping (inner) case width	343 mm
Shipping (inner) case height	275 mm
Shipping (inner) case length	565 mm
Shipping (inner) case weight	7297 g
Shipping (inner) case net weight	6390 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	42 pc(s)
Quantity per shipping (inner) case	6 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	158.8 mm
Height	69.4 mm
Weight	500 g
