D-Link DWL-6610AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 515
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Ad Hoc Client Status
An ad hoc client is a wireless client that gains access to the WLAN through a wireless client that is associated
with an access point. The ad hoc client does not communicate directly with the AP. Ad hoc networks are a
particular concern because they consume RF bandwidth and can present a security risk.
From the WLAN > Monitoring > Client > Ad Hoc Clients page, you can view and manage wireless clients that
are connected to the WLAN through an ad hoc network.
Figure 339: Ad Hoc Clients
To view or configure the default action specified for a wireless client (Allow, Deny, or Global Action), go to the
WLAN > Administration > Advanced Configuration > Clients > Known Client page and click the MAC address
of the client to view or configure.
The switch does not remove MAC entries from this list even when a client successfully authenticates with an
AP. The historical ad hoc data gives you more time to take action against clients that establish ad hoc networks
on the WLAN.
Table 306: Associated Client TSPEC Statistics
Field Description
TS Packets Received Count of packets received by an AP from a wireless client for the specified access
category.
TS Bytes Received Count of bytes received by an AP from a wireless client for the specified access
category.
TS Packets Transmitted Count of packets transmitted by an AP to a wireless client for the specified access
category.
TS Bytes Transmitted Count of bytes transmitted by an AP to a wireless client for the specified access
category.

D-Link DWL-6610AP Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Certification	CE EN 301 893 V1.7.1 (2012-06) (DFS/TPC) EN 300 328 V1.8.1 (2012-06) FCC IC cUL LVD UL2043 C-Tick BSMI NCC
Housing material	Plastic
Antenna gain level (max)	6.5 dBi
Security algorithms	AES, HTTPS, SSH, TKIP, WPA, WPA2
Output current	2 A
Output voltage	12 V
Power consumption (max)	16.6 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN (RJ-45) ports	1
Package depth	235 mm
Package width	243 mm
Package height	90 mm
Package weight	1065 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1235 mm
Pallet height (sea)	2060 mm
Pallet gross weight (air)	200628 g
Pallet gross weight (sea)	332474 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	252 pc(s)
Shipping (inner) case width	343 mm
Shipping (inner) case height	275 mm
Shipping (inner) case length	565 mm
Shipping (inner) case weight	7297 g
Shipping (inner) case net weight	6390 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	42 pc(s)
Quantity per shipping (inner) case	6 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	158.8 mm
Height	69.4 mm
Weight	500 g
