General| DSL WAN | - |
|---|---|
| Ethernet WAN | Yes |
| WAN connection type | RJ-45 |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 1200 Mbit/s |
| WLAN data transfer rate (first band) | 866 Mbit/s |
| WLAN data transfer rate (second band) | 300 Mbit/s |
| 4G standard | LTE-TDD & LTE-FDD |
| 2G standards | GPRS, GSM |
| 3G standards | UMTS |
| 4G bands supported | 800, 900, 1800, 2100, 2600 MHz |
| GSM bands supported | 850, 900, 1800, 1900 MHz |
| UMTS bands supported | 900, 2100 MHz |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11ac, IEEE 802.11n |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA2 |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Operating relative humidity (H-H) | 10 - 90 % |
| Sustainability certificates | CE, RoHS |
| Power source type | DC |
| USB port | No |
| Ethernet LAN (RJ-45) ports | 2 |
| Product type | Portable router |
| Product color | Black |
| LED indicators | LAN, Power, WLAN |
| Harmonized System (HS) code | 85176990 |
| Cables included | LAN (RJ-45) |
Weight and Dimensions| Depth | 126 mm |
|---|---|
| Width | 132 mm |
| Height | 44 mm |
| Weight | 300 g |
