D-Link DWR-960 User Manual

DWR-960
3
ENGLISH
TROUBLESHOOTING
SETUP AND CONFIGURATION PROBLEMS
1. HOW DO I CONFIGURE MY DWR-960 ROUTER OR CHECK MY WIRELESS
NETWORK NAME (SSID) AND WIRELESS ENCRYPTION KEY?
- Connect your PC to the router using an Ethernet cable.
- Open a web browser and enter the router's IP address: http://192.168.0.1
- Log into the router using the default username admin, the default password is (leave the eld blank).
- Once logged in, you will be prompted to change the username and password from the default.
- Use the wizard located under Internet settings to congure the router, or make changes manually.
Note: If you have changed the password and cannot remember it, you will need to reset the
router to factory defaults.
2. HOW DO I RESET MY DWR-960 ROUTER TO FACTORY DEFAULT SETTINGS?
- If you cannot remember your router administrator password, you may use an implement such as
a straightened paperclip to press and hold the reset button on the front of the router for about
10 seconds.
Note: Resetting the router to factory default will erase the current conguration. To recongure
your router, log in as outlined in question 1, then run the Setup Wizard.
3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY
WIRELESS NETWORK NAME (SSID) OR WIRELESS ENCRYPTION KEY?
- Every PC that needs to connect to the router wirelessly, you will need to ensure you use the
correct Wireless Network Name (SSID) and encryption key.
- Use the web based user interface (as described in question 1 above) to check or choose your
wireless settings.
- Make sure you write down these settings so that you can enter them into each wirelessly
connected PC. You will nd a dedicated area on the back of this document, this important
information for future use.
4. WHY AM I UNABLE TO ESTABLISH AN INTERNET CONNECTION?
- If connecting using a 4G mobile connection, make sure that you are within range of the mobile
service provider, and that the service has been correctly congured.
- If connecting using the WAN via ADSL/Cable service, make sure the modem has been enabled/
connected and is operational, and that the service is correctly congured.
TECHNICAL SUPPORT
dlink.com/support

D-Link DWR-960 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	866 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
4G standard	LTE-TDD & LTE-FDD
2G standards	GPRS, GSM
3G standards	UMTS
4G bands supported	800, 900, 1800, 2100, 2600 MHz
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	CE, RoHS
Power source type	DC
USB port	No
Ethernet LAN (RJ-45) ports	2
Product type	Portable router
Product color	Black
LED indicators	LAN, Power, WLAN
Harmonized System (HS) code	85176990
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	126 mm
Width	132 mm
Height	44 mm
Weight	300 g
