D-Link DWR-960 User Manual

DWR-960
7
FRANÇAIS
CONTENU DE LA
BOÎTE
TABLE DES MATIÈRES
ADAPTATEUR SECTEUR 12V, 1A
CÂBLE ETHERNET
Contactez immédiatement votre revendeur s’il manque l’un de
ces éléments de la boîte.
ROUTEUR SANS FIL AC1200 4G LTE
DWR-960
2 X ANTENNES SABRES 4G

D-Link DWR-960 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	866 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
4G standard	LTE-TDD & LTE-FDD
2G standards	GPRS, GSM
3G standards	UMTS
4G bands supported	800, 900, 1800, 2100, 2600 MHz
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	CE, RoHS
Power source type	DC
USB port	No
Ethernet LAN (RJ-45) ports	2
Product type	Portable router
Product color	Black
LED indicators	LAN, Power, WLAN
Harmonized System (HS) code	85176990
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	126 mm
Width	132 mm
Height	44 mm
Weight	300 g
