D-Link DWR-M960 - Rear Panel

User Manual of DWR-M960
-18-
LED
STATE
FUNCTION
POWER
On
Device power on
Off
Device power off
2.4G
On
The 2.4GHz Wi-Fi is activated.
Flash
Device is transmitting data wirelessly over 2.4GHz.
Off
The 2.4GHz Wi-Fi is disabled.
5.8G
On
The 5.8GHz Wi-Fi is activated.
Flash
Device is transmitting data wirelessly over 5.8GHz.
Off
The 5.8GHz Wi-Fi is disabled.
WPS
Flash
WPS is triggered
Off
WPS is connected or disable
LAN1-4
On
Link is established.
Flash
Packets are transmitting or receiving.
Off
LAN port is not connected.
WAN
On
Link is established.
Flash
Packets are transmitting or receiving.
Off
WAN port is not connected.
USB
On
USB connection is established.
Flash
Data is being transmitted.
Off
USB connection is not established.
On
LTE or 3G is connected
LTE
Off
LTE or 3G is not connected
Table 2-1 LED Indications
2.1.3 Rear Panel
The rear panel provides the physical connectors connected to the power adapter and any other network device.
Figure 2-4 shows the rear panel of the DWR-M960.
