D-Link DWR-M960 - Page 8

User Manual of DWR-M960
-11-
Data Rates
2.4GHz up to 300Mbps
5GHz up to 867Mbps
Channel
2.4GHz
FCC (America): 2.412~2.462GHz (11 Channels)
ETSI (Europe): 2.412~2.472GHz (13 Channels)
5GHz
5.180-5.240GHz, 5.745-5.825GHz (up to 9 channels)
*The actual channels in application will vary depending on the regulation
in different regions and countries.
Channel Width
802.11ac: 20/40/80MHz
802.11n: 20/40MHz
Max. RF Power / EIRP
2.4GHz: < 20dBm
5GHz: < 20dBm
Receive Sensitivity
2.4GHz
11b (11Mbps): -79dBm
11g (54Mbps): -68dBm
11n (20M) mode: -67dBm
11n (40M) mode: -64dBm
5GHz
11a: -74dBm
11n (20M) mode: -70dBm
11n (40M) mode: -67dBm
11ac (20M) mode: -67dBm
11ac (40M) mode: -61dBm
11ac (80M) mode: -57dBm
SSID
2.4GHz: 1 Root SSID and 4 Guest SSID
5GHz: 1 Root SSID and 4 Guest SSID
Wireless Management Features
Encryption Security
WEP
WPA/WPA2 personal mixed mode
Wireless Security
Wireless ACL MAC address filtering
Supports WPS (Wi-Fi Protected Setup )
2.4GHz wireless: 32
