CHAPTER-3
D-Link GLB-802C ADSL2+ Router User Manual 10
Predefined connection for major ISPs with their VPI and VCI values are available in the device.
IMPORTANT NOTE: Kindly reconfirm the values of VPI/VCI with the Internet Service Providers.
Connection name VPI VCI
MTNL 0 32
BSNL 0 35
Airtel 1 32
VSNL 0 33
3.3.2.1 To set the router in BRIDGE mode {Ethernet over ATM (RFC 1483 Bridge)}, go to Quick
configuration,
• Select the appropriate Connection name.
• “Enabled” in Operation mode,
• Connection type as “Bridge mode”
• “RFC1483 Bridge IP LLC (or) RFC1483 Bridge IP VC-Mux” as Encapsulation, (as provided by
ISP)
• Enter the VPI and VCI as provided by ISP,
• And, click “Submit” to save the settings.
