6D-Link DIR-X1860 User Manual
Section 1 - Product Overview
1 Power Connector Connector for the supplied power adapter.
2 Power Button Press the power button to power the device on or off.
3 Reset Button
Insert a paperclip in the hole, wait for 10 seconds, then release to reset the router to default
settings
.
4 Gigabit LAN Ports (1- 4)
Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game
consoles.
5 Gigabit WAN Port Using an Ethernet cable, connect your broadband modem to this port.
6 WPS Button
Press to start the WPS process and automatically create an encrypted connection to a WPS
client.
Back
41 2 3 5
6
