62D-Link M15 User Manual
Section 3 - Conguration
Port Forwarding
If you edit or create a rule, the following options will appear:
Name Enter a name for the rule.
Local IP Enter the IP address of the device on your local network to which
the port will be forwarded. Alternatively, select the device from the
drop-down menu.
TCP Port Enter the TCP ports that you want to forward. You can enter a single
port or a range of ports. Separate ports with a comma (for example:
24,1009,3000-4000).
UDP Port Enter the UDP ports that you want to forward. You can enter a single
port or a range of ports. Separate ports with a comma (for example:
24,1009,3000-4000).
Schedule Use the drop-down menu to select the time schedule that the rule
will be enabled on. The schedule may be set to Always Enable, or
you can create your own schedules in the Schedule section. Refer to
Time & Schedule - Schedule on page 70 for more information.
for more information.
Click Apply when you are done.
Go to Features > Port Forwarding to specify a port or range of ports to
open for specic devices on the network. This might be necessary for certain
applications to connect through the router. For example, access from the
Internet can be redirected to a DMZ host using Port Forwarding.
To congure the Virtual Server settings, click the Virtual Server link. Refer to
Virtual Server on page 63.
If you want to remove a rule, click
in the Delete column. If you wish to edit
a rule, click
in the Edit column. If you wish to create a new rule, click the
Add Rule button.

Other manuals for D-Link M15

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link M15 and is the answer not in the manual?

D-Link M15 Specifications

General IconGeneral
SecurityWPA3
MU-MIMOYes
BeamformingYes
Product TypeMesh Wi-Fi System
ModelM15
Parental ControlsYes
Guest NetworkYes
Mobile AppD-Link Wi-Fi App
Voice ControlAmazon Alexa, Google Assistant
Frequency BandsDual-band
Wi-Fi SpeedAX1500
Security ProtocolsWPA3, WPA2, WPA
Maximum Data Rate1500 Mbps
Ethernet Ports (Per Unit)1 x Gigabit WAN port, 2 x Gigabit LAN ports
