44D-Link WNA-1330 User Manual
Section 4 - Wireless Security
Configure WPA/WPA2 Passphrase
Using the D-Link Utility
It is recommended to enable WPA-PSK on your wireless router or access point before configuring your wireless adapter. If you are
joining an existing network, you will need to know the WPA-PSK passphrase being used.
1. Open the Wireless Utility by double-clicking on the D-Link icon in your
system tray (lower-right corner of screen).
2. Highlight the wireless network (SSID) you would like to connect to
and click Connect. If the network is using WPA-PSK, the screen (as
shown to the left) will appear.
3. Enter the WPA-PSK passphrase exactly as it is on your wireless router
or access point. Click the Show text in the password field box to see
the passphrase. Unchecking it will hide it.
4. Click OK to connect to the network. Allow up to 30 seconds to connect.
If you would like to create a new network and enter the WEP settings, refer to the next page.
To Next Page
