xStack® DES-3200 Series Layer 2 Ethernet Managed Switch Hardware Installation Guide
37
Performance
Transmission Method
Store-and-forward
Packet Buffer
1.5MB per device
Packet Filtering/
Forwarding Rate
14,881 pps (10M port)
148,810 pps (100M port)
1,488,100 pps (1Gbps port)
MAC Address Learning
Automatic update. Supports 16K MAC address
Priority Queues
8 Priority Queues per port
Forwarding Table Age
Time
Max age: 10-1000000 seconds. Default = 300.
LED Indicators:
Location LED Indicative Color Status Description
Solid Light Power on.
Power
Green
Light off Power off.
Solid Light Console on.
Blinking POST is in progress.
Console
Green
Light off Console off.
Solid Light Attached device failure is detected.
Alarm (DES-3200-
28/ME only)
Red
Light off
Attached device is off or functioning
properly.
Blinking Light When any of the fans has failed.
Fan
(DES-3200-
28F/28P/52/52-
DC/52P only)
Red
Light off When all fans work normally.
Link
Green Solid Light
When 10/100Mbps port is in Link/Act
Mode.
Per Device
Port LED Mode
(DES-3200-
28P/52P only)
PoE
Green Solid Light When 10/100Mbps port is in PoE Mode.
Solid Light RPS in use
RPS (Only for
Redundant
Power)
Green
Light Off RPS not in use
Solid Green
When there is a secure 10/100Mbps
Ethernet connection (or link) at any of the
ports.
Blinking Green
When there is reception or transmission
(i.e. Activity—Act) of data occurring at a
Fast Ethernet connected port.
LED Per
10/100Mbps
Copper Port
Link/Act
Green
Light off No link.
Solid Green When there is a secure 1000Mbps
Ethernet connection (or link) at any of the
ports.
Blinking Green When there is reception or transmission
(i.e. Activity—Act) of data occurring at a
1000Mbps Ethernet connected port.
LED Per
10/100/1000Mbps
Copper Port
Link/Act/Speed
Green/Amber
Solid Amber When there is a secure 10/100Mbps Fast
Ethernet connection (or link) at any of the
ports.
