xStack® DES-3200 Series Layer 2 Ethernet Managed Switch Hardware Installation Guide
100Mbps SF
P Ports
(DES-3200-28F Only)
Compliant to the following standards:
IEEE 802.3 compliance
IEEE 802.3u compliance
Support Full-Duplex operations
IEEE 802.3x flow control support in full-duplex mode
SFP (Mini GBIC) Support:
DEM-210 (100BASE-FX, Single-mode, 15km)
DEM-211 (100BASE-FX, Multi-mode, 2km)
DEM-220T (TX-1550/RX-1310nm, Single-mode, 20km)
DEM-220R (TX-1310/RX-1550nm, Single-mode, 20km)
100/1000Mbps SFP Ports
Compliant to the following standards:
IEEE 802.3u compliance
IEEE 802.3z compliance
SFP (Mini GBIC) Support:
DEM-210 (100BASE-FX, Single-mode, 15km)
DEM-211 (100BASE-FX, Multi-mode, 2km)
DEM-310GT (1000BASE-LX, Single-mode, 10km)
DEM-311GT (1000BASE-SX, Multi-mode, 550m)
DEM-312GT2 (1000BASE-SX, Multi-mode, 2km)
DEM-314GT (1000BASE-LHX, Single-mode, 50km)
DEM-315GT (1000BASE-ZX, Single-mode, 80km)
DGS-712 (1000BASE-T, 100m) NOTE: This transceiver together with
the Switch does not support flow control and will only operate at
1000Mbps.
WDM Transceiver Supported:
DEM-220T (TX-1550/RX-1310nm, Single-mode, 20km)
DEM-220R (TX-1310/RX-1550nm, Single-mode, 20km)
DEM-330T (TX-1550/RX-1310nm, Single-mode, 10km)
DEM-330R (TX-1310/RX-1550nm, Single-mode, 10km)
DEM-331T (TX-1550/RX-1310nm, Single-mode, 40km)
DEM-331R (TX-1310/RX-1550nm, Single-mode, 40km)
10/100Mbps Power Over Ethernet Ports
(DES-3200-28P/52P Only)
IEEE 802.3af compliant
IEEE 802.3at compliant
NOTE: The SFP combo ports on the Switch cannot be used simultaneously with the corresponding
1000BASE-T ports. If both ports are in use at the same time (ex. port 25 of the SFP and port 25 of
the 1000BASE-T), the SFP ports will take priority over the combo ports and render the 1000BASE-T
ports inoperable.
39
