TENSIONED LARGE ADVANTAGE
®
ELECTROL
®
INSTALLATION
CASE LENGTH
VARIABLE
POSITION
MOUNTING
BRACKETS
8
1
/2 "
11"
ELECTRICAL
JUNCTION BOX
8
1
/2 "
11
1
/2 "
9
1
/8"
(SUGGESTED)
1
/2"
THREADED ROD (NOT
INCLUDED) ATTACHED
TO MOUNTING
BRACKET
FINISHED
CEILING
SELF-TRIMMING
FLANGE
12
3
/16"
13
1
/8"
11
7
/16"
11"
