Large Cosmopolitan
®
Electrol
®
Installation For 240V Screens
With A Built-In Low Voltage Control
Low-Voltage Wall Switch
Optional IR and RF
Remote Control
Splitter
Motor
Ground to Case
240VAC 50Hz
240V Wiring Diagram
With Optional Built-In
Low Voltage Control
Up
Stop
Down
Ground–Must be
Connected to
Building Ground
Green
Front Back
UP DN
GND +5V
3Position
Switch
RJ9
UP +5V COM DN
IMPORTANT NOTE: The wall switch is REQUIRED to make
any limit switch adjustments, EVEN if a third party control
system is used. Therefore, it is advised to wire the switch or
provide a 4-conductor connection that is accessible.
Connect Supplied
RJ9 Cable to Splitter
and Switch, or use 4
Cable Conductor to
Connect to Screw
Terminals.
ILT RJ9 Pin-Outs (Tab Is Facing Up)
Ground Common
IR or Up
+5V
Data or Down
Red
Green
White
Black
Green
Brown (Hot)
Blue (Common)
RJ9RJ9
Dry Contacts
