④ SIG+ : Sensor Ouput Signal + Connection Terminal
⑤ SIG- : Sensor Output Signal – Connection Terminal
⑥ GND : SHIELD connection terminal of sensor
⑦ : Ground Terminal (as an independent ground connection.)
⑧ INC : External Input Common Terminal
⑨ IN1 : External HOLD Input Terminal
⑩ IN2 : External ZERO Input Terminal
⑪ RYC : RELAY Common Terminal
⑫ RY1 : RELAY1(Lower Limit) Output Terminal
⑬ RY2 : RELAY2 (Normal) Output Terminal (OK )
⑭ RY3 : RELAY3 (Upper Limit) Output Terminal
⑮ GND, TXD, RXD : RS232C SERIAL INTERFACE Terminal
(RS485 : TXD -> TX+, RXD -> TX-)
○
16E
A GND, OUT : Analog out Terminal (DC ±10V or DC 4~20mA)
◀Attention▶
1. When wiring, please pull out the power plug. (Main power supply)
2. Please use the thick calbe for ground terminal ( ) so that you can avoid any trouble
due to the impulse voltage or surge. If possible, please keep it as an independent
ground.
(This must be used in the area with heavy noise. If the ground is made with other
device, it will be affected by noise.)
3. Please check the function of the terminal before you do the wiring so that you can
prevent any malfunction in advance.
4. Manufacture will be relieved of its responsibility for any damge or injury due to the
disassembly and alteration made without any agreement. Also, no A/S will be made.
