F-41. Baud rate (Communication Speed Setup)
(Standard setup value : 9.60)
Display data Setting
2.40 2400 bps
4.80 4800 bps
9.60 9600 bps
19.20 19200 bps
38.40 38400 bps
57.60 57600 bps
PRINT PRINT DATA OUT (PT-100)
F-42. Protocol (Communication Protocol set up)
(Standard setup value : 0)
Display data Setting
0 Standard protocol
1 Modbus RTU Protocol
F-50. Display reverse mode (Direction setting, mark reverse)
(Standard setup value : 0)
Display data Setting
0 Positive mark
1 Negative mark
2 Display as absolute value
F-51. Force unit (Conversion unit set up)
(Standard setup value : 0)
Display data Setting
0 kgf kg/㎠
1 N kgf × 9.8 - -
2 ℓb kgf × 2.2 - -
3 - - Bar kg/㎠ × 0.98
4 - - MPa kg/㎠ × 0.098
Note1) When setting the conversion unit (set value: 1 to 4), calibration modes of 8-3
and 8-4 are not available.
After calibrating in kgf (set value:0), set the force unit as desired.
Note2) If F-51 is set to MPa (set value:4), the F-00 Decimal point setting cannot be
changed.
