Dishwasher Service Manual
Troubleshooting and Repair
75
6. Removing WPS Sensor & Pressure Switch
The WPS sensor is mounted to the front of the sump with two small phillips head screws.
• Remove the two screws and the wire plug from the sensor and remove from dishwasher.
• The pressure switch can be removed from its mount by removing the two screws,
disconnecting the wires and the hose connected to the sump
Pressure Switch
WPS Sensor
6a
6c
6b
To Next Page
