CONNETTORI
Connettore di potenza Speakon
CONNECTOR
Speakon power connector
Ground
Hot (+)
Cold (-)
INPUT OUTPUT
Connettore di segnale XLR XLR signal connector
SPEAKER POWER OUTPUTS
2-
1+
2+
1-
20mm
0.8"
8mm
0.3"
RED
BLACK
channel 2 positive
n.c.
1+
channel 2 negative
1-
n.c.
OUTPUT CH2
2-
1+
2+
1-
channel 1 positive
1+
channel 1 negative
1-
OUTPUT CH1
2+
bridge positive
bridge negative
SX1000
2-
1+
2+
1-
channel 1 positive
1+
channel 1 negative
1-
OUTPUT CH1
SX1500 / SX2000
INPUT
