DAD SX2000 - Technical Specifications

26
I
GB
SX1000 SX1500 SX2000
SPECIFICHE TECNICHE TECHNICAL SPECIFICATION
Technical Data SX1000 SX1500 SX2000
8 Ohm stereo power
(EIA/THD1%)
310Wx2 450Wx2 600Wx2
4 Ohm stereo power
(EIA/THD1%)
500Wx2 750Wx2 1000Wx2
2 Ohm stereo power
(THD1%) Pulse
600Wx 2 1000Wx 2 1250Wx2
8 Ohm bridge power
(EIA/THD1%)
1100W 1500W 2000W
4 Ohm bridge power
(THD1%) Pulse
1200W 2000W 2600W
Frequency response 20Hz-20khz@ 8 Ohm -0,5 dB
THD N <0.05%
Slew rate >20V/us
Damping factor >200
Dynamic range 80dB
S/N rate >90dB
Input sensitivity 0,775V/1,0V
Input impedance
(balance/unbalance)
Balance 20K / Unbalance 10K
Output circuit class Class AB 2 Steps class H 2 Steps class H
Protection Soft-start, short circuit, DC, overheat, clip/limit, VHF
Cooling air-flow Airow from front panel to rear panel
Power voltage /
frequency
~230V ±10%/50Hz
Dimensions (WxHxD)
483x89x445 mm 483x89x496 mm 483x89x496 mm
Net weight 6,85 kg 9 kg 9,2 kg
Gross weight 8,75 kg 10,9 kg 11 kg
