9
PARTS LOCATION
HEADLIGHT
FR. FENDER
FR. CUSHION
SIDE STAND
SIDE STAND SWITCH
MAIN STAND
FR. BRAKE DISK
BRAKE CALIPER
RR. BRAKE LEVER
FUEL TANK LID
MAIN SEAT
PILLION SEAT
REAR COMBI.
LIGHT
AIR CLEANER

Table of Contents

Other manuals for DAELIM S2 125

Preview: Service Manual
Service Manual184 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DAELIM S2 125 and is the answer not in the manual?

DAELIM S2 125 Specifications

General IconGeneral
Displacement124.6 cc
Fuel SystemCarburetor
Front SuspensionTelescopic Fork
Rear BrakeDrum
Front Tire120/70-12
Rear Tire130/70-12
Cooling SystemAir-cooled
TransmissionAutomatic (CVT)
Front BrakeDisc
