DAELIM S2 125 Owner's Manual

<SPEEDOMETER>
Indicates driving speed. Maintain legal
speed limits to ensure safe operation.
<ODOMETER>
Indicates total distance in kilometers
travelled by the vehicle.
<FUEL METER>
The fuel meter indicates the gasoline level
inside the fuel tank.
Gasoline should be put in the fuel tank as
soon as possible if the needle is resting in
the red area.
FUEL TANK CAPACITY : 11
ℓℓ
RESERVIOR CAPACITY : 2.8
ℓℓ
<WINKER INDICATOR>
When the winker switch is operated,
the winker indicator flashes in union
with the flashing of the turn signals.
10
METER READING AND USAGE
METER
INDICATOR LAMPS
SPEEDOMETER
FUEL METER
HEADLIGHT
HIGHBEAM
INDICATOR
WINKER
INDICATOR
WINKER
INDICATOR
ODOMETER
ODOMETER
RESET BUTTON

DAELIM S2 125 Specifications

General

Displacement	124.6 cc
Fuel System	Carburetor
Front Suspension	Telescopic Fork
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air-cooled
Transmission	Automatic (CVT)
Front Brake	Disc
