43
Turn off the main switch to see if the fuse
is severed. If the fuse is severed, exchange
the fuse into a fuse with same capacity.
Fuse is installed in fuse box around the
battery.
To change a fuse, first take off fuse
cover. Then, remove the disconnected
fuse, and insert the reserved fuse with
same capacity.
If the fuse immediately becomes
severed after being changed with the
new one, check another problem of the
electric system. Contact to Daelim
service center.
FUSE REPLACEMENT
CAUTION
Do not use screw driver or other metal
parts to remove the fuse, as short
circuit can be occurred to cause
damage to electric system.
Do not use a fuse having a larger
voltage, as the wire can become
overheated and damaged.
When replacing any of the electrical
parts (lights and gauges), be sure to
replace them with the recommended
parts. Using different parts can lead to
the fuses burning out or damage to the
battery.
When washing the vehicle, take special
care not to allow to be splashed in the
area of the fuses.
PILLION SEAT BATTERY COVER FUSE HOLDER
<DISASSEMBLY> <ASSEMBLY>
