<Reassembly order>
1. By-pass valve 4. By-pass valve plug
2. By-pass valve spring 5. Element gasket
3. O-ring : plug 6. Element(DB58 3plates. T/Ti 4plales)
��
Dil cooler element tigthening bolts
Tighten the bolts with the specified torque after
assemble an oil cooler element.
��
Reassembly
Reassembly shall be inverted inverted from the disassambled.
Torque 2.6±0.5 kg∙m
6
1
2
3
4
5
