Daewoo DB58 - 3.3. Oil Cooler Service

- 99 -
3.3. Oil Cooler
��
Disassembly
EJM3008S
<System of Disassembly>
1. Element (NA 3 plates. T/TI 4 plates) 4. O-ring ; plug
2. Element gasket 5. By-pass valve spring
3. By-pass vlave plug 6. By-pass valve
Inspection and Repair
Correct and replace if it is found the worn, defect or others when check it.
1
6
5
4
3
2
