Daewoo DB58 - 5.3. Injection Pump Service; 5.3.1. Injection Quantity Adjustment

5.3. Injection Pump
5.3.1. Adjustment of Injection quantity.

CAUTION

Injection quantity shall be adjusted as
it is seeing adjustment data of
injection pump model as described
"A".
5.3.2 Calibration data
DB58
<Test conditions>
- 115 -
101605-9100
0000000000000000000
Pump NO.- 000000000
S6A95C410RS2000
LICENCE BOSCH
EJM5014I
Injection pump 101605-9630
Injection nozzle D.K.K.C.P.No. 105025-1380
Injection nozzle holder D.K.K.C.P.No. 105160-4650
Nozzle opening pressure 180 kg/cm2
Injection pipe demensions INNER DIA. 1.6mmXOUTER DIA. 6 mm -
LENGTH 580 mm
Transter pump pressure 1.6 kg/cm2
Testing diesel fuel ISO 4
Operating temperature 40~50°C
<Governor Adjustment>
0
B
E
C
A
340
480
415
350
850
970
1175
1115
9.8
9.1
9.4
6.3
6.4
+
_
0.1
0.3
+ _
0.1
+
_
20
14
OR MORE
EJM5015I
