Importance
��
Unit Bearing
By untilizing bench press set up the unit
bearing at the pump.
��
Snap Ring
Assemble the snap ring with the snap ring plier.
��
Pulley Center
Assemble pulley center with the bench press.
��
Washer and Seal Unit
Assemble it with the bench press after is is
spreaded the sealant to pump body contacting
surface.
EJM4011I
EJM4007S
EJM4015S
EJM4016S
EJM4017S
Spreading of multipurposable grease
Outside from sealed surface
Spreading of
sealant
To Next Page
