Daewoo DB58 - Page 39

DB58TI
- 36 -
4
11
3
5
8
9
12
10
1
6
7
2
EJM2006I
<Disassembly Steps>
1. Cooling fan
2. Fuel retrun pipe
3. Fuel pipe: fuel filter to injection pump
4. Fuel pipe; feed pump to filter
5. I/P boocom hose
6. Coolant inlet pipe in inter cooler
7. Coolant outlet pipe in outlet pipe
8. Injection pipe
9. Oil pile: oil filter- oil cooler
10. Injection pump
11. Fuel filter
12. Oil filter
