Daewoo DB58 - 2.2.6. Cylinder Head Disassembly

- 45 -
2.2.6. Cylinder Head Disassembly Steps
DB58
Importance

Split collar
Use the valve spring compressor when remove
split collar
EJM2027S
EJM2024S
<Disassembly Steps>
1. Exhaust manifold and gasket 7. Spring seat (upper) or *Valve rotator
2. Intake manifold and gasket 8. Valve spring
3. Coolant outlet pipe 9. Spring seat (lower)
4. Thermostat 10. Valve
5. Thermostat housing and gasket 11. Valve stem oil seal
6. Sprint collar
Valve spring compressor
