Daewoo DB58 - Page 79

- 76 -

Intake Manifold and Gasket
1) Assembly the intake manifold that
unchamfered corner is 'up' toward inside
engine.
2) After assemble intake manifold, and
systematically assemble the bolt with the
specified torque.(see figure)

Exhaust Manifold and Gasket
1) Assemble the exhaust manifold and gasket
that it is seeing "TOP" at the front side.
2) After assemble the exhaust manifold, and
systematically assemble blots with the
specified torque.(see figure)
2) Assemble the spacer tube. (see figure)
EJM2114S
EJM2115S
TOP
EJM2116I
EJM2117S
EJM2118S
Intake Manifold Bolt Torque 2. 6±0.5 kg∙m
Exhaust Manifold Bolt Torque 2. 9±0.5 kg∙m
Rear of Unchamfered corner
Rear
Spacer tube
Spot face
