EJM2169I
<Reassembly Steps>
1. Oil filter 8. Coolant inlet pipe in inter cooler
2. Fuel filter 9. I/P boocom hose
3. Injection pump 10. Fuel pipe; feed pump to filter
4. Oil pile: oil filter- oil cooler 11. Fuel pipe: fuel filter to injection pump
5. Injection piper 12. Fuel retrun pipe
6. Inter cooler 13. Cooling fan
7. Coolant outlet pipe in outlet pipe
To Next Page
