Daewoo DLT-22W4T - Antenna Connection; Direct Aerial Connection

16
COMMON INTERFACE
ANT
Antenna Connection
Aerial Connection
CONNECTING THE TV DIRECTLY TO AN AERIAL
Connect an aerial cable (75 ohm coaxial cable) to the Aerial terminal on the back of the TV set.
Aerial
Aerial cable
Aerial terminal
DLT-20J1T / DLT-20J3T / DLT-20J9T
DLT-19W4T / DLT-22W4T / DLT-19L1T / DLT-22L1T / DLT-19L2T / DLT-22L2T
