Part List
-61-
RS803 RS01Z823J- R M-OXIDE FILM 1W 82K OHM J (TAPPING)
ZZ200 PTPWJRG116 PCB POWER RADIAL AS DLP-32C2AMSB
C812 CCXR3A101K C CERA 1KV R 100PF K
C815 CMXM2A223J C MYLAR 100V 0.022MF J TP
C816 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C817 CMXL1J105J C MYLAR 63V MEU 1MF J
C818 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C819 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C820 CXSL2H100D C CERA 500V SL 10PF D (TAPPING)
C821 CXSL2H100D C CERA 500V SL 10PF D (TAPPING)
C829 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C831 CMXL1J105J C MYLAR 63V MEU 1MF J
C836 CEXF1H470C C ELECTRO 50V RUS 47MF (6.3X11) TP
C838 CMXM2A683J C MYLAR 100V 0.068MF J (TP)
C846 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C855 CMXL1J474J C MYLAR 63V MEU 0.47MF J
CS808 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
CS809 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
CS810 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
CS815 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
I805 1K1A431B-- IC REGULATOR(SHUNT) KIA431B 2.495V 0.5% TO-92
L841 58C0000096 COIL CHOKE 610G0233(470K)
Q804 TKTC3203Y- TR KTC3203-Y
Q805 TKTC3203Y- TR KTC3203-Y
ZZ200 PTPWJAG116 PCB POWER AXIAL AS DLP-32C2AMSB
510 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
520 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859816111 PCB POWER 246X246 D1L
D805 DD1NS47060 DIODE D1NS4-7060
D806 DZEG01C--- DIODE EG01C
D807 DUF4007--- DIODE UF4007 DO-41 1000V 1A
D809 DUF4007--- DIODE UF4007 DO-41 1000V 1A
D810 DUF4007--- DIODE UF4007 DO-41 1000V 1A
D812 DUZ24BM--- DIODE ZENER UZ-24BM
D813 DZEG01C--- DIODE EG01C
D845 D1N4937G-- DIODE 1N4937G (TAPPING)
D850 D1N4148--- DIODE 1N4148 (TAPPING)
DS806 DRU1P----- DIODE RU1P
DS807 DRGP15JP-- DIODE RGP-15JP
DS808 DUZ6R2BM-- DIODE ZENER UZ-6.2BM
DS810 DRGP15JP-- DIODE RGP-15JP
J800 85801060GY WIRE COPPER 1/0.6 TIN COATING
J801 85801060GY WIRE COPPER 1/0.6 TIN COATING
J802 85801060GY WIRE COPPER 1/0.6 TIN COATING
J804 85801060GY WIRE COPPER 1/0.6 TIN COATING
J805 85801060GY WIRE COPPER 1/0.6 TIN COATING
J806 85801060GY WIRE COPPER 1/0.6 TIN COATING
J807 85801060GY WIRE COPPER 1/0.6 TIN COATING
J809 85801060GY WIRE COPPER 1/0.6 TIN COATING
J810 85801060GY WIRE COPPER 1/0.6 TIN COATING
J811 85801060GY WIRE COPPER 1/0.6 TIN COATING
J812 85801060GY WIRE COPPER 1/0.6 TIN COATING
J813 85801060GY WIRE COPPER 1/0.6 TIN COATING
J814 85801060GY WIRE COPPER 1/0.6 TIN COATING
J815 85801060GY WIRE COPPER 1/0.6 TIN COATING
J816 85801060GY WIRE COPPER 1/0.6 TIN COATING
J858 85801060GY WIRE COPPER 1/0.6 TIN COATING
L804 5MC0000100 COIL BEAD HC-3550
L805 5MC0000100 COIL BEAD HC-3550
L806 5MC0000100 COIL BEAD HC-3550
R804 RD-2Z474J- R CARBON FILM 1/2 470K OHM J
R811 RN-4Z4703F R METAL FILM 1/4 470K OHM F
R812 RN-4Z4703F R METAL FILM 1/4 470K OHM F
R813 RN-4Z3003F R METAL FILM 1/4 300K OHM F
R814 RN-4Z8203F R METAL FILM 1/4 820K OHM F
R815 RN-4Z8203F R METAL FILM 1/4 820K OHM F
LOC PART CODE PART NAME DESCRIPTION REMARK
R816 RN-4Z8203F R METAL FILM 1/4 820K OHM F
R817 RN-4Z7500F R METAL FILM 1/4 750 OHM F
R818 RN-4Z1602F R METAL FILM 1/4 16.0K OHM F
R824 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R825 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R827 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R828 RD-4Z479J- R CARBON FILM 1/4 4.7 OHM J
R829 RD-4Z479J- R CARBON FILM 1/4 4.7 OHM J
R831 RD-4Z105J- R CARBON FILM 1/4 1M OHM J
R837 RD-4Z331J- R CARBON FILM 1/4 330 OHM J
R838 RD-4Z333J- R CARBON FILM 1/4 33K OHM J
R848 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R853 RD-4Z223J- R CARBON FILM 1/4 22K OHM J
R855 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R885 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K
RS805 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
RS806 RD-2Z129J- R CARBON FILM 1/2 1.2 OHM J
ZZ330 PTUNSWG151 PCB UNION AS DLP-26C3AMBS
100 2193110012 SOLDER WIRE SAC3000 3.0MM (LFA3C0-W3.0)
200 2193110024 SOLDER WIRE SAC3005 1.6MM (LFA3-107-W1.6)
300 2291050623 FLUX SOLDER LF SV-PBF-304P(0.823)
400 2291050312 FLUX SOLVENT S-3000
IC290 1TS0P34838 IC PREAMP TSOP34838SJ
LED1 DSPR39MVW- LED SPR-39MVW (DUAL)
M232 4852333201 PANEL CTRL HIPS BK
M491 4854964311 BUTTON CH ABS GY
M491A 7178301051 SCREW TAPPTITE TT2 WAS 3X10 MFZN 3CR
P911C 4850705N40 CONNECTOR 12505HS-05+12505HS-05+ULW+CORE=600
P912C 4850706N26 CONNECTOR 12505HS-06+12505HS-06+ULW+CORE=550
ZZ200 PTUNJRG151 PCB UNION RADIAL AS DLP-26C3AMBS
SW201 5S50101Z90 SW TACT THVV502GDA
SW202 5S50101Z90 SW TACT THVV502GDA
SW203 5S50101Z90 SW TACT THVV502GDA
SW204 5S50101Z90 SW TACT THVV502GDA
SW205 5S50101Z90 SW TACT THVV502GDA
SW206 5S50101Z90 SW TACT THVV502GDA
SW207 5S50101Z90 SW TACT THVV502GDA
ZZ200 PTUNJ1G151 PCB UNION CHIP A AS DLP-26C3AMBS
110 2193220010 SOLDER CREAM(PB-FREE) LST309-M(SN+3.0AG/0.5CU)
A001 4859814760 PCB UNION 189X235.5
CC293 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
PW201 49590009S0 CONN WAFER 12505WR-05A00
PW202 49590001S0 CONN WAFER 12505WR-06A00
RC270 HRFT432JBA R CHIP 1/10 4.3K OHM J 1608
RC271 HRFT152JBA R CHIP 1/10 1.5K OHM J 1608
RC272 HRFT152JBA R CHIP 1/10 1.5K OHM J 1608
RC273 HRFT432JBA R CHIP 1/10 4.3K OHM J 1608
RC274 HRFT113JBA R CHIP 1/10 11K OHM J 1608
LOC PART CODE PART NAME DESCRIPTION REMARK
